F9/F9 Pro အတြက္ သတ္မွတ္ခ်က္ Parameter List

Views: 0 • Likes: 0

Content Description

F9/F9 Pro Specification Parameter List

Name

Model	CPH1823/CPH1825/CPH1881
Market name	F9/F9PRO
Marketing date	Aug.2018

Screen

Screen size	6.3inch
Touch screen	Capacitive Screen Multi-touch
Screen texture	TFT-LTPS
Touch panel technology	incell
Screen resolution	2340*1080
Screen PPI	409PPI
Narrow frame	1.697mm
Screen ratio	January/00
Screen Contrast	1500:1（Typ）
Screen colors	16.7M
Color saturation	NTSC 81.5% （Typ）
Maximum brightness	450(Typ)
Touch screen supplier	DPT,DSBJ,TM,AUO
Touch screen type	Corning Gorilla Glass *
Touch panel glass type	Corning Gorilla Glass *

Network

VoLTE	TH：AIS DTAC TRUE IN：JIO AIRTEL VODAFONE KH：Smart Seatel
4G+	Asia Pacific Lite： GSM: 850/900/1800/1900MHz WCDMA: 850/900/2100MHz FDD-LTE: Bands 1/3/5/8 TD-LTE: Bands 38/40/41（2535-2655MHz） Asia Pacific： GSM: 850/900/1800/1900MHz WCDMA: 850/900/2100MHz FDD-LTE: Bands 1/3/5/7/8 TD-LTE: Bands 38/40/41（2535-2655MHz） Full-band version： GSM: 850/900/1800/1900MHz WCDMA: 850/900/2100MHz FDD-LTE: Bands 1/3/5/7/8/20/28 TD-LTE: Bands 38/40/41（2535-2655MHz）
4G data rate	Asia Pacific Lite/Asia Pacific：150Mbps/75Mbps Full-band version：150Mbps/75Mbps
HSPA data rate	42.2Mbps/11.4Mbps
SIM card type and size	Dual nano-SIM
Network type	GSM，WCDMA， FDD LTE ，TD-LTE
Data service	GPRS/EDGE/WCDMA/HSPA/HSPA+/LTE
CDMA data rate	NA
WLAN Display	Yes
Bluetooth version	BT2.1(+EDR)/BT4.2

Press key type	Virtual keys
Body color	Stellar Purple Sunrise Red
Size	156.7mm74.0mm7.99mm
Weight	About 169g

System

Android version	8.1.0
ColorOS version	5.2
Face recognition	Yes
Split screen(specific Apps)	Yes, it need the clarify of applications, includes：Facebook、WhatsApp、BBM、Telegram、imo、messenger、viber、LINE、WeChat、Youtube、PLAY、MXplayer、video、17 Media、Dubsmash、Chrome、GMail
Kids space	Yes
Clone Apps	Yes，(Wechat、hike、Instagram、WhatsApp,Line,BBm,Messager、imo、telegram)
Night Shield	Yes
sensor hub	YES
Game Acceleration(Specific Apps)	Yes，include the mainstream games such as Candy Crash, Temple Run 2, Pokemon Go, Asphalt 8
Oshare(aim at the Indian phone numers' recognition）	Supports OPPO share, no phone number recognition for India
Face recognition time	0.6s
Program frozen	Yes
File encryption	Yes

Cpu

CPU core	8
CPU platform	MTK P60
CPU frequency	2.0GHZ
GPU Model	ARM Mali-G72 MP3 800MHz
Baseband architecture	4x A73：2.0GHz,4x A53:2.0GHz
CPU technology	12nm

RAM	4G/6G
RAM technology	LPDDR4X
ROM	64G
ROM technology	EMMC 5.1
External memory	256G
Standard TF card equipped	NO

Endurance

Full charge time(0-100%)	1h 40min（vooc） 4h 30min（CPH1881）
VOOC flash charge	YES
Wireless charge	NO
Battery capacity	3500mAh（TYP） 3415mAh（MIN）
Theoretical Calling duration	MAX GSM:30 hours; WCDMA: 22hours
Theoretical standby duration	Max 300 Hours
Energy density	October/01
Charge speed/power	5V 4A，20W
Simulated duration	12:43 - 6G ram 13:19 - 4G ram
Theoretical Audio playing time	28h10min
Mechanical hand test data	18:14 - 6G ram 19:00 - 4G ram
Theoretical Video playing time	7h25min

Other Hardware

Headset jack	3.5mm
USB jack	Micro-USB
Infrared ray remote control	NO
Built-in battery	Yes
Battery type	Li-polymer Battery
SAR value	CPH1823/CPH1825: CE SAR: ≤2.0W/kg(Head) ≤2.0W/kg(Body) IN SAR： 1.312W/kg(Head) 0.829W/kg(Body)　 CPH1881: IN SAR： 0.92W/kg(hHead) 0.572W/kg(Body)
GPS	GPS/Agps/GLONASS/Beidou
Map Apps	Google Maps
Gyro-meter	YES
Flashlight	YES
Hall Sensor/Window-view mode	NO
Notification light	NO
Double mic noise suppression	YES
Fingerprint	YES
Magnetic induction	YES
Light sensor	YES
Proximity Sensor	YES
G-sensor/Acceleration sensor	YES
OTG	YES
WLAN	YES
Connection and sharing	Yes
Design of card slot	Dual nano-SIM + microSD card
FM	Yes
SIM card plugging method	Needle (left)

Front Camera

PPI	25M
Sensor Sizes/pixel data	1/2.78，0.9um
Sensor type	CMOS
Sensor model/manufacturers	IMX576/SONY
Wide angle of front	79°
Aperture	F2.0
Focal length	3.82mm
Lens number	5P
Video	Yes
Characteristic function for photograph	Beauty, Filter, HDR, PANO
Photo management

Rear Camera

PPI	16M+2M
Sensor Sizes/pixel data	1/3.1,1.0um
Sensor type	CMOS
Optical focusing	NO
Maximum Zoom multiples	4X
Aperture	F1.85
Focal length	3.62mm
Flashlight	Yes
Lens number	5P
Video	1080P、720P
Characteristic function for photograph	Beauty, Filter, HDR, PANO, Ultra Clear
Photo management	YES
Number of Output Pixels for ultra-high definition	4312*5760=25M
Consecutive Capture modes	Yes
Soft Light	No
Focusing method	Digital zoom
Image stabilizer	Yes
SR AUTO	Yes


Image size

Rear camera：4608*3456、3456*3456、4608*2128
Front Camera：5760*4312、4312*4312、5760*2656

Basic Function

Text Input	Yes
Calls records	3000
Group send upper limit	SMS：200 MMS：15

Entertainment Function

Video format	AVI/3GP/MP4/WMV/MKV/MOV/ASF/FLV
Image format	JPEG/PNG/GIF/BMP
E-book	iReader（ID/MY/TH/TW/SG）
Game	Support Download
Built-in APPs	GMS related apps、facebook、WPS
Record format	mp3
Video record format	MP4
Ringtone format	MP3/AMR/APE/OGG/FLAC/WAV/MIDI/WMA
Support HD	YES
Webpage video play	Yes
Sound effect type	dirac
E-mail	G-mail

Business Function

world time	Yes
Data back	Yes
Office tools	WPS
Firewall	Support SMS blocking and call blocking
NFC	No
Files compression and decompression	Yes
Timed message send	No
Import and export messages	No
Import and export contacts	Yes
Contacts capacity	According to the ROM

Other Function

\

Package List

Handset	1
Adapter	1
Headset	1
Micro USB Cable	1
Important Info. Booklet with Warranty Card	1
Quick Guide	1
SIM Card Tool	1
Screen Protect Film	1
Case	1
