OPPO A16 (CPH2269/CPH2275) Parameter List
Views: 0 • Likes: 0
| Version | South America | Asia Pacific (Fewer Frequency Bands) |
All Frequency Bands (Including 3 GB + 32 GB Version for Vietnam) |
All Frequency Bands (Including 4 GB + 64 GB Version for Vietnam) |
1.Basic information |
||||
| Product name | OPPO A16 | OPPO A16 | OPPO A16 | OPPO A16 |
| Phone model | CPH2269 | CPH2269 | CPH2269 | CPH2275 |
| Launch date | 2021/10/24 | 2021/7/15 | 2021/7/25 | 2021/7/25 |
2.Appearance |
||||
| Dimensions | 75.6 mm x 163.8 mm x 8.4 mm | 75.6 mm x 163.8 mm x 8.4 mm For Indian regions: 7.56 cm x 16.38 cm x 0.84 cm |
75.6 mm x 163.8 mm x 8.4 mm | 75.6 mm x 163.8 mm x 8.4 mm |
| Weight | About 190 g | About 190 g | About 190 g | About 190 g |
| Phone color | Crystal Black Pearl Blue |
Crystal Black Pearl Blue Space Silver Royal Gold |
Crystal Black Pearl Blue Space Silver |
Crystal Black Pearl Blue Space Silver |
| Product Appearance | ||||
3.Material and process |
||||
| Material of top motherboard case | Aluminum alloy (QN32) + Plastic (PC + 20% glass fiber) | Aluminum alloy (QN32) + Plastic (PC + 20% glass fiber) | Aluminum alloy (QN32) + Plastic (PC + 20% glass fiber) | Aluminum alloy (QN32) + Plastic (PC + 20% glass fiber) |
| Material of bottom motherboard case | PC plastics | PC plastics | PC plastics | PC plastics |
| Material of battery cover | Sheet material (PC + PMMA) | Sheet material (PC + PMMA) | Sheet material (PC + PMMA) | Sheet material (PC + PMMA) |
| Process of battery cover | 1. Black: UV transfer patterns + Brightness-enhancement film plating + High gloss coating 2. Silver: UV transfer patterns + Bright indium film plating + Matte coating 3. Blue: Tinted sheet material + UV transfer pattens + Bright indium film plating + Matte coating |
1. Black: UV transfer patterns + Brightness-enhancement film plating + High gloss coating 2. Silver: UV transfer patterns + Bright indium film plating + Matte coating 3. Blue: Tinted sheet material + UV transfer pattens + Bright indium film plating + Matte coating 4. Gold (India): UV transfer pattens + Dip dyeing + Indium film plating + Matte coating |
1. Black: UV transfer patterns + Brightness-enhancement film plating + High gloss coating 2. Silver: UV transfer patterns + Bright indium film plating + Matte coating 3. Blue: Tinted sheet material + UV transfer pattens + Bright indium film plating + Matte coating |
1. Black: UV transfer patterns + Brightness-enhancement film plating + High gloss coating 2. Silver: UV transfer patterns + Bright indium film plating + Matte coating 3. Blue: Tinted sheet material + UV transfer pattens + Bright indium film plating + Matte coating |
| Protective film on battery cover | None | None | None | None |
| Oleophobic coating on battery cover | Yes | Yes | Yes | Yes |
4.SoC |
||||
| Highest CPU clock rate | 2.3 GHz with 8 cores (4 big cores + 4 little cores) | 2.3 GHz with 8 cores (4 big cores + 4 little cores) | 2.3 GHz with 8 cores (4 big cores + 4 little cores) | 2.3 GHz with 8 cores (4 big cores + 4 little cores) |
| GPU model | IMG GE8320 @ 680 MHz | IMG GE8320 @ 680 MHz | IMG GE8320 @ 680 MHz | IMG GE8320 @ 680 MHz |
| CPU architecture | 4 x A53 2.3 GHz L2 cache 512 KB 4 x A53 1.8 GHz L2 cache 512 KB |
4 x A53 2.3 GHz L2 cache 512 KB 4 x A53 1.8 GHz L2 cache 512 KB |
4 x A53 2.3 GHz L2 cache 512 KB 4 x A53 1.8 GHz L2 cache 512 KB |
4 x A53 2.3 GHz L2 cache 512 KB 4 x A53 1.8 GHz L2 cache 512 KB |
| RAM clock speed | 1600 MHz | 1600 MHz | 1600 MHz | 1600 MHz |
| CPU model | MediaTek Helio G35 | MediaTek Helio G35 | MediaTek Helio G35 | MediaTek Helio G35 |
| Processing platform (Internal name) | MT6765V/CB | MT6765V/CB | MT6765V/CB | MT6765V/CB |
| Processor (Public name) | MediaTek Helio G35 | MediaTek Helio G35 | MediaTek Helio G35 | MediaTek Helio G35 |
| CPU manufacturing process | 12 nm | 12 nm | 12 nm | 12 nm |
| GPU manufacturing process | 12 nm | 12 nm | 12 nm | 12 nm |
| AI capabilities | No | No | No | No |
| CPU cores | 8 | 8 | 8 | 8 |
| Processor bits | 64-bit | 64-bit | 64-bit | 64-bit |
5.Display |
||||
| Size | Size(screen diagonal) SMetric: 16.55 cm Imperial: 6.52" |
Size (screen diagonal) Metric: 16.55 cm Imperial: 6.52" |
Size (screen diagonal) Metric: 16.55 cm Imperial: 6.52" |
Size(screen diagonal) Metric: 16.55 cm Imperial: 6.52" |
| Top bezel | 2.44 mm | 2.44 mm | 2.44 mm | 2.44 mm |
| Bottom bezel | 6.6 mm | 6.6 mm | 6.6 mm | 6.6 mm |
| Left and right bezels | 1.98 mm | 1.98 mm | 1.98 mm | 1.98 mm |
| Screen-to-body ratio | 88.7% | 88.7% | 88.7% | 88.7% |
| Color saturation | 71% NTSC (Typical) |
71% NTSC (Typical) |
71% NTSC (Typical) |
71% NTSC (Typical) |
| Colors | 16.7 million colors (8-bit) | 16.7 million colors (8-bit) | 16.7 million colors (8-bit) | 16.7 million colors (8-bit) |
| Aspect ratio | 20:09 | 20:09 | 20:09 | 20:09 |
| Material of display panel | LCD | LCD | LCD | LCD |
| Suppliers | Holitech, Innolux, TXD | Holitech, Innolux, TXD | Holitech, Innolux, TXD | Holitech, Innolux, TXD |
| Resolution | 720 x 1600 (HD+) | 720 x 1600 (HD+) | 720 x 1600 (HD+) | 720 x 1600 (HD+) |
| Color gamut | 71% NTSC (Typical) | 71% NTSC (Typical) | 71% NTSC (Typical) | 71% NTSC (Typical) |
| Pixel density | 269 PPI | 269 PPI | 269 PPI | 269 PPI |
| Contrast ratio | 1500:1 (Typical) | 1500:1 (Typical) | 1500:1 (Typical) | 1500:1 (Typical) |
| Brightness | 480 nits (Typical) | 480 nits (Typical) | 480 nits (Typical) | 480 nits (Typical) |
| Touch screen material | Homegrown Panda glass (Reinforced once) | Homegrown Panda glass (Reinforced once) | Homegrown Panda glass (Reinforced once) | Homegrown Panda glass (Reinforced once) |
| Refresh rate | 60 Hz | 60 Hz | 60 Hz | 60 Hz |
| Lamination method of touch screen | In-cell | In-cell | In-cell | In-cell |
| Touch points | Multiple touch points (Max: 10 touch points) | Multiple touch points (Max: 10 touch points) | Multiple touch points (Max: 10 touch points) | Multiple touch points (Max: 10 touch points) |
| Touch sampling rate | 60 Hz | 60 Hz | 60 Hz | 60 Hz |
| Screen protector type | General 2D protective film | General 2D protective film | General 2D protective film | General 2D protective film |
| Oleophobic coating on screen | No | No | No | No |
| Oleophobic coating on protective film from manufacturer | No | No | No | No |
| TÜV Rheinland eye comfort certification | None | None | None | None |
| Night mode | Supported | Supported | Supported | Supported |
| Eye comfort | Supported | Supported | Supported | Supported |
| Low-brightness flicker-free eye comfort | Not supported | Not supported | Not supported | Not supported |
| HDR display | Not supported | Not supported | Not supported | Not supported |
| Touch screen type | Capacitive | Capacitive | Capacitive | Capacitive |
6.Storage |
||||
| RAM and ROM capacities | 4 GB + 64 GB | 3 GB + 32 GB 4 GB + 64 GB |
3 GB + 32 GB 4 GB + 64 GB |
4 GB + 64 GB |
| RAM | LPDDR4x @ 2133 MHz, 2 x 16-bit | LPDDR4x @ 1867 MHz 2 × 16-bit (3 GB + 32 GB) LPDDR4x @ 2133 MHz 2 × 16-bit (4 GB + 64 GB) |
LPDDR4x @ 1867 MHz 2 × 16-bit (3 GB + 32 GB) LPDDR4x @ 2133 MHz 2 × 16-bit (4 GB + 64 GB) |
LPDDR4x @ 2133 MHz, 4 x 16-bit |
| ROM | eMMC 5.1 | eMMC 5.1 | eMMC 5.1 | eMMC 5.1 |
| Phone storage card | MicroSD card (Max storage: 256 GB) | MicroSD card (Max storage: 256 GB) | MicroSD card (Max storage: 256 GB) | MicroSD card (Max storage: 256 GB) |
| Expansion card | MicroSD card (Max storage: 256 GB) | MicroSD card (Max storage: 256 GB) | MicroSD card (Max storage: 256 GB) | MicroSD card (Max storage: 256 GB) |
| Moving apps to storage card | Not supported | Not supported | Not supported | Not supported |
| OTG data transmission | Supported | Supported | Supported | Supported |
| OTG storage formats | FAT32, NTFS, EXFAT | FAT32, NTFS, EXFAT | FAT32, NTFS, EXFAT | FAT32, NTFS, EXFAT |
| Maximum OTG storage | 2 TB | 2 TB | 2 TB | 2 TB |
| RAM channels | 2 | 2 | 2 | 2 |
7.Front camera |
||||
| Effective focal length | 2.75 mm | 2.75 mm | 2.75 mm | 2.75 mm |
| Camera specifications | 8MP (f/2.0); FOV79°; 5P Lens | 8MP (f/2.0); FOV79°; 5P Lens | 8MP (f/2.0); FOV79°; 5P Lens | 8MP (f/2.0); FOV79°; 5P Lens |
| Sensor specifications | Samsung S5K4H7YX03, 8MP, 4:3, 1/4', 1.12 ㎛ | Samsung S5K4H7YX03, 8MP, 4:3, 1/4', 1.12 ㎛ | Samsung S5K4H7YX03, 8MP, 4:3, 1/4', 1.12 ㎛ | Samsung S5K4H7YX03, 8MP, 4:3, 1/4', 1.12 ㎛ |
| Focusing mode | Fixed focus | Fixed focus | Fixed focus | Fixed focus |
| Camera mode | Photo, Portrait, Panorama, Video, Time-lapse | Photo, Portrait, Panorama, Video, Time-lapse | Photo, Portrait, Panorama, Video, Time-lapse | Photo, Portrait, Panorama, Video, Time-lapse |
| Photo details | Device name: OPPO A16 Focal length: 2.75 mm Aperture: f/2.0 |
Device name: OPPO A16 Focal length: 2.75 mm Aperture: f/2.0 |
Device name: OPPO A16 Focal length: 2.75 mm Aperture: f/2.0 |
Device name: OPPO A16 Focal length: 2.75 mm Aperture: f/2.0 |
| Image size | Maximum size: 3264 x 2448 (Normal mode) Photo sizes in different aspect ratios: 3264 x 2448 (4:3) 2448 x 2448 (1:1) 3264 x 1472 (full screen) 3264 x 1840 (16:9) |
Maximum size: 3264 x 2448 (Normal mode) Photo sizes in different aspect ratios: 3264 x 2448 (4:3) 2448 x 2448 (1:1) 3264 x 1472 (full screen) 3264 x 1840 (16:9) |
Maximum size: 3264 x 2448 (Normal mode) Photo sizes in different aspect ratios: 3264 x 2448 (4:3) 2448 x 2448 (1:1) 3264 x 1472 (full screen) 3264 x 1840 (16:9) |
Maximum size: 3264 x 2448 (Normal mode) Photo sizes in different aspect ratios: 3264 x 2448 (4:3) 2448 x 2448 (1:1) 3264 x 1472 (full screen) 3264 x 1840 (16:9) |
| Image format | JPG | JPG | JPG | JPG |
| Video shooting | Front camera: 1080P/720P@30 fps (Default: 720P@30 fps; beautification turned on) Video zoom or slow motion is not supported by the front camera. |
Front camera: 1080P/720P@30 fps (Default: 720P@30 fps; beautification turned on) Video zoom or slow motion is not supported by the front camera. |
Front camera: 1080P/720P@30 fps (Default: 720P@30 fps; beautification turned on) Video zoom or slow motion is not supported by the front camera. |
Front camera: 1080P/720P@30 fps (Default: 720P@30 fps; beautification turned on) Video zoom or slow motion is not supported by the front camera. |
| Video formats | Video format: MP4 Video coding format: H.264 |
Video format: MP4 Video coding format: H.264 |
Video format: MP4 Video coding format: H.264 |
Video format: MP4 Video coding format: H.264 |
| Optical zoom | Not supported | Not supported | Not supported | Not supported |
| EIS (Electronic image stabilization) | Not supported | Not supported | Not supported | Not supported |
| Soft light | Not supported | Not supported | Not supported | Not supported |
| Camera structure | Front camera: Waterdrop notch | Front camera: Waterdrop notch | Front camera: Waterdrop notch | Front camera: Waterdrop notch |
| Camera control | Touch the screen, press the Volume button, or use gestures to take photos. | Touch the screen, press the Volume button, or use gestures to take photos. | Touch the screen, press the Volume button, or use gestures to take photos. | Touch the screen, press the Volume button, or use gestures to take photos. |
| Sensor type | CMOS | CMOS | CMOS | CMOS |
| Material of protection glass | Panda glass (Reinforced once) | Panda glass (Reinforced once) | Panda glass (Reinforced once) | Panda glass (Reinforced once) |
| Front camera arrangement | 8MP | 8MP | 8MP | 8MP |
| Equivalent focal length | 26 mm | 26 mm | 26 mm | 26 mm |
8.Rear camera |
||||
| Sensor specifications | Main camera: OV OV13B10, 13MP, 1/3.06", 1.12 um, 4:3, AF Mono camera: GalaxyCore GC02M1B, 2MP, 1/5", 1.75 um Macro camera: OV OV02B10, 2MP, 1/5", 1.75 um |
Main camera: OV OV13B10, 13MP, 1/3.06", 1.12 um, 4:3, AF Mono camera: GalaxyCore GC02M1B, 2MP, 1/5", 1.75 um Macro camera: OV OV02B10, 2MP, 1/5", 1.75 um |
Main camera: OV OV13B10, 13MP, 1/3.06", 1.12 um, 4:3, AF Mono camera: GalaxyCore GC02M1B, 2MP, 1/5", 1.75 um Macro camera: OV OV02B10, 2MP, 1/5", 1.75 um |
Main camera: OV OV13B10, 13MP, 1/3.06", 1.12 um, 4:3, AF Mono camera: GalaxyCore GC02M1B, 2MP, 1/5", 1.75 um Macro camera: OV OV02B10, 2MP, 1/5", 1.75 um |
| Camera specifications | Main camera: f/2.2; FOV 80°; 5P lens; AF Mono camera: f/2.4; FOV 88.8°; 3P lens; FF Macro camera: f/2.4; FOV 88.8°; 3P lens; FF |
Main camera: f/2.2; FOV 80°; 5P lens; AF Mono camera: f/2.4; FOV 88.8°; 3P lens; FF Macro camera: f/2.4; FOV 88.8°; 3P lens; FF |
Main camera: f/2.2; FOV 80°; 5P lens; AF Mono camera: f/2.4; FOV 88.8°; 3P lens; FF Macro camera: f/2.4; FOV 88.8°; 3P lens; FF |
Main camera: f/2.2; FOV 80°; 5P lens; AF Mono camera: f/2.4; FOV 88.8°; 3P lens; FF Macro camera: f/2.4; FOV 88.8°; 3P lens; FF |
| Effective focal length | Main camera: 3.46 mm; Mono camera: 1.77 mm; Macro camera: 1.77 mm | Main camera: 3.46 mm; Mono camera: 1.77 mm; Macro camera: 1.77 mm | Main camera: 3.46 mm; Mono camera: 1.77 mm; Macro camera: 1.77 mm | Main camera: 3.46 mm; Mono camera: 1.77 mm; Macro camera: 1.77 mm |
| Equivalent focal length | Main camera: 26 mm; Mono camera: 24 mm; Macro camera: 34 mm | Main camera: 26 mm; Mono camera: 24 mm; Macro camera: 34 mm | Main camera: 26 mm; Mono camera: 24 mm; Macro camera: 34 mm | Main camera: 26 mm; Mono camera: 24 mm; Macro camera: 34 mm |
| Optical zoom | Not supported | Not supported | Not supported | Not supported |
| EIS (Electronic image stabilization) | Not supported | Not supported | Not supported | Not supported |
| OIS(Optical image stabilization) | Not supported | Not supported | Not supported | Not supported |
| Focusing mode | Main camera: Phase focus | Main camera: Phase focus | Main camera: Phase focus | Main camera: Phase focus |
| Camera mode | Photo, Portrait, Night, Panorama, Expert, Video, Time-lapse, Macro | Photo, Portrait, Night, Panorama, Expert, Video, Time-lapse, Macro | Photo, Portrait, Night, Panorama, Expert, Video, Time-lapse, Macro | Photo, Portrait, Night, Panorama, Expert, Video, Time-lapse, Macro |
| Image format | JPG | JPG | JPG | JPG |
| Video shooting | Rear camera: up to 1080P@30 fps, and 720P@30 fps Video zoom: 1080P@30 fps |
Rear camera: up to 1080P@30 fps, and 720P@30 fps Video zoom: 1080P@30 fps |
Rear camera: up to 1080P@30 fps, and 720P@30 fps Video zoom: 1080P@30 fps |
Rear camera: up to 1080P@30 fps, and 720P@30 fps Video zoom: 1080P@30 fps |
| Video formats | Video format: MP4 Video coding format: H.264 (With high compatibility) |
Video format: MP4 Video coding format: H.264 (With high compatibility) |
Video format: MP4 Video coding format: H.264 (With high compatibility) |
Video format: MP4 Video coding format: H.264 (With high compatibility) |
| Flashlight | One rear LED light with single color temperature | One rear LED light with single color temperature | One rear LED light with single color temperature | One rear LED light with single color temperature |
| Camera control | Touch the screen or press the Volume button. | Touch the screen or press the Volume button. | Touch the screen or press the Volume button. | Touch the screen or press the Volume button. |
| Smart scenario recognition | Not supported | Not supported | Not supported | Not supported |
| Sensor type | CMOS | CMOS | CMOS | CMOS |
| Material of protection glass | Caihong twice-reinforced glass | Caihong twice-reinforced glass | Caihong twice-reinforced glass | Caihong twice-reinforced glass |
| Rear camera arrangement | 13 MP main camera + 2 MP mono camera + 2 MP macro camera | 13 MP main camera + 2 MP mono camera + 2 MP macro camera | 13 MP main camera + 2 MP mono camera + 2 MP macro camera | 13 MP main camera + 2 MP mono camera + 2 MP macro camera |
| Zoom mode | 5x digital zoom supported | 5x digital zoom supported | 5x digital zoom supported | 5x digital zoom supported |
| Burst photos | 20 photos | 20 photos | 20 photos | 20 photos |
| Photo editing options | Filter, Sticker, Retouch, Blur, Mosaic | Filter, Sticker, Retouch, Blur, Mosaic | Filter, Sticker, Retouch, Blur, Mosaic | Filter, Sticker, Retouch, Blur, Mosaic |
| Photo details | Main camera: Device name: OPPO A16 Focal length: 3.46 mm Aperture: f/2.2 Mono camera: Device name: OPPO A16 Focal length: 1.77 mm Aperture: f/2.4 Macro camera: Device name: OPPO A16 Focal length: 1.77 mm Aperture: f/2.4 |
Main camera: Device name: OPPO A16 Focal length: 3.46mm Aperture: f/2.2 Mono camera: Device name: OPPO A16 Focal length: 1.77 mm Aperture: f/2.4 Macro camera: Device name: OPPO A16 Focal length: 1.77 mm Aperture: f/2.4 |
Main camera: Device name: OPPO A16 Focal length: 3.46mm Aperture: f/2.2 Mono camera: Device name: OPPO A16 Focal length: 1.77 mm Aperture: f/2.4 Macro camera: Device name: OPPO A16 Focal length: 1.77 mm Aperture: f/2.4 |
Main camera: Device name: OPPO A16 Focal length: 3.46mm Aperture: f/2.2 Mono camera: Device name: OPPO A16 Focal length: 1.77 mm Aperture: f/2.4 Macro camera: Device name: OPPO A16 Focal length: 1.77 mm Aperture: f/2.4 |
| Image size | Maximum size: 4160 x 3120 (normal photos) Photo sizes in different aspect ratios: 4160 x 3120 (4:3) 3120 x 3120 (1:1) 4160 x 1872 (full screen) 4160 x 2340 (16:9) |
Maximum size: 4160 x 3120 (normal photos) Photo sizes in different aspect ratios: 4160 x 3120 (4:3) 3120 x 3120 (1:1) 4160 x 1872 (full screen) 4160 x 2340 (16:9) |
Maximum size: 4160 x 3120 (normal photos) Photo sizes in different aspect ratios: 4160 x 3120 (4:3) 3120 x 3120 (1:1) 4160 x 1872 (full screen) 4160 x 2340 (16:9) |
Maximum size: 4160 x 3120 (normal photos) Photo sizes in different aspect ratios: 4160 x 3120 (4:3) 3120 x 3120 (1:1) 4160 x 1872 (full screen) 4160 x 2340 (16:9) |
| Fill light for video shooting | Supported | Supported | Supported | Supported |
9.OS – Version info and apps |
||||
| Android version | Android 11 | Android 11 | Android 11 | Android 11 |
| ColorOS version | ColorOS 11.1 | ColorOS 11.1 | ColorOS 11.1 | ColorOS 11.1 |
| OPPO apps | Clone Phone, Clock, My Files (File Manager), Music, Theme Store, Camera, Photos, Phone Manager, Weather, HeyTap Cloud, Calculator, OPPO Relax, Recorder, Screen Lock, Compass, Videos, Music Party, and ORoaming | Clone Phone, Clock, My Files (File Manager), Music, Theme Store, Camera, Photos, Phone Manager, Weather, HeyTap Cloud, Calculator, OPPO Relax, Recorder, Screen Lock, Compass, Videos, Music Party, and ORoaming | Clone Phone, Clock, My Files (File Manager), Music, Theme Store, Camera, Photos, Phone Manager, Weather, HeyTap Cloud, Calculator, OPPO Relax, Recorder, Screen Lock, Compass, Videos, Music Party, and ORoaming | Clone Phone, Clock, My Files (File Manager), Music, Theme Store, Camera, Photos, Phone Manager, Weather, HeyTap Cloud, Calculator, OPPO Relax, Recorder, Screen Lock, Compass, Videos, Music Party, and ORoaming |
| Pre-installed third-party apps | Universal：Google Suite，Google File，Facebook，FB Installer, FB Manager, FBNS，WPS Office Different countries and regions：Amazon Shopping，Amazon Prime Video，Lazada，TikTok(com.ss.android.ugc.trill)，Whatsapp，Messenger，Wetv |
In common：Google Suite，Google File，Facebook，FB Installer, FB Manager, FBNS，WPS Office Different countries and regions：Amazon Shopping，Amazon Prime Video，Lazada，TikTok(com.ss.android.ugc.trill)，Whatsapp，Messenger，Wetv |
In common：Google Suite，Google File，Facebook，FB Installer, FB Manager, FBNS，WPS Office Different countries and regions：Amazon Shopping，Amazon Prime Video，Lazada，TikTok(com.ss.android.ugc.trill)，Whatsapp，Messenger，Wetv |
In common：Google Suite，Google File，Facebook，FB Installer, FB Manager, FBNS，WPS Office Different countries and regions：Amazon Shopping，Amazon Prime Video，Lazada，TikTok(com.ss.android.ugc.trill)，Whatsapp，Messenger，Wetv |
| Apps that can be uninstalled | In common: Google Mobile Services, Google File, Facebook, FB Installer, FB Manager, FBNS, and WPS Office Vary by country/region: Amazon Shopping, Amazon Prime Video, Lazada, TikTok (com.ss.android.ugc.trill), Whatsapp, Messenger, WeTV, Weather, Calculator, OPPO Relax, Recorder, Screen Lock, Compass, Videos, Music Party, and ORoaming. |
In common: Google Mobile Services, Google File, Facebook, FB Installer, FB Manager, FBNS, and WPS Office Vary by country/region: Amazon Shopping, Amazon Prime Video, Lazada, TikTok (com.ss.android.ugc.trill), Whatsapp, Messenger, WeTV, Weather, Calculator, OPPO Relax, Recorder, Screen Lock, Compass, Videos, Music Party, and ORoaming. |
In common: Google Mobile Services, Google File, Facebook, FB Installer, FB Manager, FBNS, and WPS Office Vary by country/region: Amazon Shopping, Amazon Prime Video, Lazada, TikTok (com.ss.android.ugc.trill), Whatsapp, Messenger, WeTV, Weather, Calculator, OPPO Relax, Recorder, Screen Lock, Compass, Videos, Music Party, and ORoaming. |
In common: Google Mobile Services, Google File, Facebook, FB Installer, FB Manager, FBNS, and WPS Office Vary by country/region: Amazon Shopping, Amazon Prime Video, Lazada, TikTok (com.ss.android.ugc.trill), Whatsapp, Messenger, WeTV, Weather, Calculator, OPPO Relax, Recorder, Screen Lock, Compass, Videos, Music Party, and ORoaming. |
| Apps that cannot be uninstalled | Netflix, Clone Phone, Clock, My Files (File Manager), Music, Theme Store, Camera, Photos, Phone Manager, and Cloud Service | Netflix, Clone Phone, Clock, My Files (File Manager), Music, Theme Store, Camera, Photos, Phone Manager, and Cloud Service | Netflix, Clone Phone, Clock, My Files (File Manager), Music, Theme Store, Camera, Photos, Phone Manager, and Cloud Service | Netflix, Clone Phone, Clock, My Files (File Manager), Music, Theme Store, Camera, Photos, Phone Manager, and Cloud Service |
| Built-in apps | OPPO apps + Pre-installed third-party apps（Line 110+Line 111） | OPPO apps + Pre-installed third-party apps（Line 110+Line 111） | OPPO apps + Pre-installed third-party apps（Line 110+Line 111） | OPPO apps + Pre-installed third-party apps（Line 110+Line 111） |
10.OS – Calls |
||||
| Dual-card single/dual pass | Dual-card single pass | Dual-card single pass | Dual-card single pass | Dual-card single pass |
| Voice call solution | VoLTE if VoLTE is enabled, and CSFB if VoLTE is not enabled | VoLTE if VoLTE is enabled, and CSFB if VoLTE is not enabled | VoLTE if VoLTE is enabled, and CSFB if VoLTE is not enabled | VoLTE if VoLTE is enabled, and CSFB if VoLTE is not enabled |
| Maximum number of call logs | 3000 | 3000 | 3000 | 3000 |
| Video call | Supported | Supported | Supported | Supported |
| Answering phone calls using earphones | Supported. | Supported. | Supported. | Supported. |
| Call recording | Supported | Supported | Supported | Supported |
| Call recording format | AMR | AMR | AMR | AMR |
| Storage location for call recordings | My Files - Phone storage - Music - Recordings - Call recordings | My Files - Phone storage - Music - Recordings - Call recordings | My Files - Phone storage - Music - Recordings - Call recordings | My Files - Phone storage - Music - Recordings - Call recordings |
| Automatic call recording | Supported | Supported | Supported | Supported |
| Quick dial | Supported | Supported | Supported | Supported |
11.OS – Contacts |
||||
| Display caller's profile picture | Supported | Supported | Supported | Supported |
| Display background for incoming calls | Supported | Supported | Supported | Supported |
| SIM card contacts import and export | Supported | Supported | Supported | Supported |
| Maximum number of contacts that can be saved | Depends on the size of phone storage space | Depends on the size of phone storage space | Depends on the size of phone storage space | Depends on the size of phone storage space |
| Maximum number of blocklisted contacts | Depends on the size of phone storage space | Depends on the size of phone storage space | Depends on the size of phone storage space | Depends on the size of phone storage space |
| Contact file formats | vCard, CSV | vCard, CSV | vCard, CSV | vCard, CSV |
| Contacts grouping | Supported | Supported | Supported | Supported |
| Customized contacts grouping | Supported | Supported | Supported | Supported |
12.OS – Messages |
||||
| Maximum number of recipients for group SMS messages | 200 | 200 | 200 | 200 |
| Maximum number of blocklisted messages | Depends on size of phone storage space | Depends on the size of phone storage space | Depends on the size of phone storage space | Depends on the size of phone storage space |
| SMS capacity | Depends on the size of phone storage space | Depends on the size of phone storage space | Depends on the size of phone storage space | Depends on the size of phone storage space |
| SMS character limit | 1530 English characters (Chinese, for encoding reasons, will be less than 1530); SMS exceeding the limit will be automatically converted to MMS. | 1530 English characters (Chinese, for encoding reasons, will be less than 1530); SMS exceeding the limit will be automatically converted to MMS. | 1530 English characters (Chinese, for encoding reasons, will be less than 1530); SMS exceeding the limit will be automatically converted to MMS. | 1530 English characters (Chinese, for encoding reasons, will be less than 1530); SMS exceeding the limit will be automatically converted to MMS. |
| Maximum size for MMS message | 300 KB | 300 KB | 300 KB | 300 KB |
| Schedule messages | Not supported | Not supported | Not supported | Not supported |
| Messages import and export | Supported | Supported | Supported | Supported |
| Number of MMS messages that can be stored | Depends on the size of phone storage space | Depends on the size of phone storage space | Depends on the size of phone storage space | Depends on the size of phone storage space |
13.OS function |
||||
| Pre-installed browser | Google Chrome | Google Chrome | Google Chrome | Google Chrome |
| Image editing function | Filter, Crop & rotate, Sticker, Retouch, Text, Mosaic, Blur, Eraser | Filter, Crop & rotate, Sticker, Retouch, Text, Mosaic, Blur, Eraser | Filter, Crop & rotate, Sticker, Retouch, Text, Mosaic, Blur, Eraser | Filter, Crop & rotate, Sticker, Retouch, Text, Mosaic, Blur, Eraser |
| Pre-loaded images | No | No | No | No |
| Pre-loaded music | No | No | No | No |
| Firewall/Block & filter | Calls and SMS messages can be blocked. | Calls and SMS messages can be blocked. | Calls and SMS messages can be blocked. | Calls and SMS messages can be blocked. |
| Backup and restore | Supported | Supported | Supported | Supported |
| File compression and extraction | Supported | Supported | Supported | Supported |
| Private Safe (File lock) | Supported | Supported | Supported | Supported |
| App lock | Supported | Supported | Supported | Supported |
| Resetting password using fingerprint | Supported | Supported | Supported | Supported |
| App lock method | Pattern lock, digit password, alphanumeric password, fingerprint, and facial recognition | Pattern lock, digit password, alphanumeric password, fingerprint, and facial recognition | Pattern lock, digit password, alphanumeric password, fingerprint, and facial recognition | Pattern lock, digit password, alphanumeric password, fingerprint, and facial recognition |
| MHL HD output | Not supported | Not supported | Not supported | Not supported |
| Split screen mode | Supported | Supported | Supported | Supported |
| Picture-in-picture (PIP) | Supported | Supported | Supported | Supported |
| Playing videos in floating window (Mini window mode) | Supported | Supported | Supported | Supported |
| Webpage video playback | Supported | Supported | Supported | Supported |
| Google Lens | Supported | Supported | Not supported | Not supported |
| Supported | Supported | Supported | Supported | |
| Reader | Supported | Supported | Supported | Supported |
| Office tools | Supported: The WPS File Viewer is pre-installed on the phone, and third-party office apps can also be installed. | Supported: The WPS File Viewer is pre-installed on the phone, and third-party office apps can also be installed. | Supported: The WPS File Viewer is pre-installed on the phone, and third-party office apps can also be installed. | Supported: The WPS File Viewer is pre-installed on the phone, and third-party office apps can also be installed. |
| Weather widget | Not supported (Weather info is included in the Clock widget.) | Not supported (Weather info is included in the Clock widget.) | Not supported (Weather info is included in the Clock widget.) | Not supported (Weather info is included in the Clock widget.) |
| Clock widget | Supported | Supported | Supported | Supported |
| Music widget | Not supported | Not supported | Not supported | Not supported |
| Third-party widget | Supported | Supported | Supported | Supported |
| Pre-installed Radio app | Supported | Supported | Not supported | Not supported |
| Gestures & motions | Screen-off gestures and 3-finger screenshot | Screen-off gestures and 3-finger screenshot | Screen-off gestures and 3-finger screenshot | Screen-off gestures and 3-finger screenshot |
| Incoming call banner | Supported | Supported | Supported | Supported |
| Press Power button to end calls | Supported | Supported | Supported | Supported |
| Kid Space (Guest mode) | Supported | Supported | Supported | Supported |
| Third-party input method | Supported | Supported | Supported | Supported |
| High-definition format | Not supported | Not supported | Not supported | Not supported |
| Audio recording formats | MP3 | MP3 | MP3 | MP3 |
| Ringtone format | MP3/AMR/APE/OGG/FLAC/WAV/MIDI/WMA | MP3/AMR/APE/OGG/FLAC/WAV/MIDI/WMA | MP3/AMR/APE/OGG/FLAC/WAV/MIDI/WMA | MP3/AMR/APE/OGG/FLAC/WAV/MIDI/WMA |
| World clock | Supported | Supported | Supported | Supported |
| Screencast through HDMI | Not supported | Not supported | Not supported | Not supported |
| Flashlight | Supported | Supported | Supported | Supported |
| Always-On Display | Not supported | Not supported | Not supported | Not supported |
| Hall effect sensor/Mini window mode | Supported | Supported | Supported | Supported |
| Screen recording | Supported | Supported | Supported | Supported |
| Compass | Supported | Supported | Supported | Supported |
| App cloner | Supported | Supported | Supported | Supported |
| OPPO Share | Supported | Supported | Supported | Supported |
| OSIE visual effect | Supported | Supported | Supported | Supported |
| Freezing third-party apps running in background | Supported | Supported | Supported | Supported |
| Voice changer | Not supported | Not supported | Not supported | Not supported |
| Game acceleration (Mainstream apps) | Not supported | Not supported | Not supported | Not supported |
| Game Space | Support basic functions: Block incoming calls, block notifications, screenshot, screen recording, open apps in a floating window | Support basic functions: Block incoming calls, block notifications, screenshot, screen recording, open apps in a floating window | Support basic functions: Block incoming calls, block notifications, screenshot, screen recording, open apps in a floating window | Support basic functions: Block incoming calls, block notifications, screenshot, screen recording, open apps in a floating window |
| Other special functions | / | / | / | / |
| OPPO Share | Supported | Supported | Supported | Supported |
| File system format | F2FS | F2FS | F2FS | F2FS |
| Game support | Arena of Valor: Display quality: Ultra-high Resolution: Ultra-high High frame rate mode: Supported PUBG: Graphics: Balanced Frame rate: Medium Highlight Reel: Not supported; Free record: Not supported. |
Arena of Valor: Display quality: Ultra-high Resolution: Ultra-high High frame rate mode: Supported PUBG: Graphics: Balanced Frame rate: Medium Highlight Reel: Not supported; Free record: Not supported. |
Arena of Valor: Display quality: Ultra-high Resolution: Ultra-high High frame rate mode: Supported PUBG: Graphics: Balanced Frame rate: Medium Highlight Reel: Not supported; Free record: Not supported. |
Arena of Valor: Display quality: Ultra-high Resolution: Ultra-high High frame rate mode: Supported PUBG: Graphics: Balanced Frame rate: Medium Highlight Reel: Not supported; Free record: Not supported. |
| Step counting method | Build-in pedometer, and third-party pedometer apps are also supported. | Build-in pedometer, and third-party pedometer apps are also supported. | Build-in pedometer, and third-party pedometer apps are also supported. | Build-in pedometer, and third-party pedometer apps are also supported. |
| Dual Wi-Fi | Not supported | Not supported | Not supported | Not supported |
| Breathing light | No | No | No | No |
| Recently deleted (Photo recycle bin) | Supported | Supported | Supported | Supported |
| Flash | Not supported | Not supported | Not supported | Not supported |
14.Local files |
||||
| Video formats | 3GP/MP4/AVI/3G2/3GPP/3GPP2/M4V/FLV/F4V/WEBM/WMV/ASF/MOV/QT/TS/M2TS/MTS/MKV/MPG/VOB | 3GP/MP4/AVI/3G2/3GPP/3GPP2/M4V/FLV/F4V/WEBM/WMV/ASF/MOV/QT/TS/M2TS/MTS/MKV/MPG/VOB | 3GP/MP4/AVI/3G2/3GPP/3GPP2/M4V/FLV/F4V/WEBM/WMV/ASF/MOV/QT/TS/M2TS/MTS/MKV/MPG/VOB | 3GP/MP4/AVI/3G2/3GPP/3GPP2/M4V/FLV/F4V/WEBM/WMV/ASF/MOV/QT/TS/M2TS/MTS/MKV/MPG/VOB |
| Audio formats | AAC/M4A/MP4/3GP/AMR/AWB/MP3/MIDI/OGG/WAV/APE/WMA/FLAC/MP2/MKV/IMY/AU/AIFF | AAC/M4A/MP4/3GP/AMR/AWB/MP3/MIDI/OGG/WAV/APE/WMA/FLAC/MP2/MKV/IMY/AU/AIFF | AAC/M4A/MP4/3GP/AMR/AWB/MP3/MIDI/OGG/WAV/APE/WMA/FLAC/MP2/MKV/IMY/AU/AIFF | AAC/M4A/MP4/3GP/AMR/AWB/MP3/MIDI/OGG/WAV/APE/WMA/FLAC/MP2/MKV/IMY/AU/AIFF |
| Supported document formats (for document viewing) | TXT, PDF, Word, Excel, and PPT | TXT, PDF, Word, Excel, and PPT | TXT, PDF, Word, Excel, and PPT | TXT, PDF, Word, Excel, and PPT |
| Image formats | BMP/JPG/WBMP/GIF/PNG/HEIC/ICO/WEBP/DNG | BMP/JPG/WBMP/GIF/PNG/HEIC/ICO/WEBP/DNG | BMP/JPG/WBMP/GIF/PNG/HEIC/ICO/WEBP/DNG | BMP/JPG/WBMP/GIF/PNG/HEIC/ICO/WEBP/DNG |
15.OPPO Wallet |
||||
| Bank cards | Not supported | Not supported | Not supported | Not supported |
| Transit card | Not supported | Not supported | Not supported | Not supported |
| eID | Not supported | Not supported | Not supported | Not supported |
| Access card | Not supported | Not supported | Not supported | Not supported |
16.Wireless connection |
||||
| NFC | Not supported | Not supported | Not supported | Not supported |
| Wi-Fi (Antenna) | Wi-Fi 2.4 GHz, Wi-Fi 5 GHz, Wi-Fi Display | Wi-Fi 2.4 GHz, Wi-Fi 5 GHz, Wi-Fi Display | Wi-Fi 2.4 GHz, Wi-Fi 5 GHz, Wi-Fi Display | Wi-Fi 2.4 GHz, Wi-Fi 5 GHz, Wi-Fi Display |
| Wi-Fi protocol | 802.11 a/b/g/n/ac | 802.11 a/b/g/n/ac | 802.11 a/b/g/n/ac | 802.11 a/b/g/n/ac |
| Maximum data rate (Theoretical) | 1.2 Gbps | 1.2 Gbps | 1.2 Gbps | 1.2 Gbps |
| Wi-Fi Display | Supported | Supported | Supported | Supported |
| Personal hotspot/Wi-Fi hotspot | Supported | Supported | Supported | Supported |
| Maximum number of devices that can be connected to a hotspot | 10 | 10 | 10 | 10 |
| Bluetooth version | Bluetooth 5.0 | Bluetooth 5.0 | Bluetooth 5.0 | Bluetooth 5.0 |
| Bluetooth codecs | SBC, AAC, aptX, LDAC | SBC, AAC, aptX, LDAC | SBC, AAC, aptX, LDAC | SBC, AAC, aptX, LDAC |
| Supported Bluetooth protocols | HFP, HSP, A2DP, AVRCP, HID, PAN, OPP, MAP, PBAP, GATT | HFP, HSP, A2DP, AVRCP, HID, PAN, OPP, MAP, PBAP, GATT | HFP, HSP, A2DP, AVRCP, HID, PAN, OPP, MAP, PBAP, GATT | HFP, HSP, A2DP, AVRCP, HID, PAN, OPP, MAP, PBAP, GATT |
| Wi-Fi antenna | 2.4 GHz/5 GHz dual band Wi-Fi | 2.4 GHz/5 GHz dual band Wi-Fi | 2.4 GHz/5 GHz dual band Wi-Fi | 2.4 GHz/5 GHz dual band Wi-Fi |
| Wi-Fi frequency | 2.4 Ghz, 5 GHz | 2.4 Ghz, 5 GHz | 2.4 Ghz, 5 GHz | 2.4 Ghz, 5 GHz |
| FM radio (Category TBD) | Supported | Supported | Supported except for EU countries | Supported |
| Share network via Bluetooth | Supported | Supported | Supported | Supported |
| 17.Mobile network | ||||
| LTE antennas | 1 main antenna + 1 diversity antenna. DPDT switch. | 1 main antenna + 1 diversity antenna. DPDT switch. | 1 main antenna + 1 diversity antenna. DPDT switch. | 1 main antenna + 1 diversity antenna. DPDT switch. |
| LTE RF technology | N/A | N/A | N/A | N/A |
| VoLTE | Supported. | Supported. | Supported. | Supported. |
| 5G network mode (Dual mode/Single mode) | Not supported | Not supported | Not supported | Not supported |
| Carriers that support VoLTE | / | / | / | / |
| Network modes | GSM, WCDMA, TD-LTE, LTE FDD | GSM, WCDMA, TD-LTE, LTE FDD | GSM, WCDMA, TD-LTE, LTE FDD | GSM, WCDMA, TD-LTE, LTE FDD |
| Data service | GPRS, EDGE, HSPA+, WCDMA, TD-LTE, LTE FDD | GPRS, EDGE, HSPA+, WCDMA, TD-LTE, LTE FDD | GPRS, EDGE, HSPA+, WCDMA, TD-LTE, LTE FDD | GPRS, EDGE, HSPA+, WCDMA, TD-LTE, LTE FDD |
| SIM card | / | / | / | / |
| Frequency band (for both SIM cards 1 and 2) | 2G: GSM 850/900/1800/1900 MHz 3G: UMTS (WCDMA) bands 1/2/4/5/6/8/19 4G: TD-LTE bands 38/41 (2535-2655 MHz) 4G: LTE FDD bands 1/2/3/4/5/7/8/12/17/18/19/28/26/66 |
2G: GSM 850/900/1800/1900 MHz 3G: UMTS (WCDMA) bands 1/5/8 4G: TD-LTE bands 38/40/41 (2535–2655 MHz) 4G: LTE FDD bands 1/3/5/8 |
2G: GSM 850/900/1800/1900 MHz 3G: UMTS (WCDMA) bands 1/5/8 4G: TD-LTE bands 38/40/41 (2496–2690 MHz) 4G: LTE FDD bands 1/3/5/7/8/20/28 |
2G: GSM 850/900/1800/1900 MHz 3G: UMTS (WCDMA) bands 1/5/8 4G: TD-LTE bands 38/40/41 (2496–2690 MHz) 4G: LTE FDD bands 1/3/5/7/8/20/28 |
| 5G network | Not supported | Not supported | Not supported | Not supported |
| 4G+ network | Not supported | Not supported | Not supported | Not supported |
| 4G network | Supported | Supported | Supported | Supported |
| 3G network | Supported | Supported | Supported | Supported |
| 2G network | Supported | Supported | Supported | Supported |
| Notes on supported frequency bands (Not to be published on our official website) |
GSM: 850/900/1800/1900 MHz WCDMA: Bands 1/2/4/5/8/6/19 FDD-LTE: Bands 1/2/3/4/5/26/18/19/7/8/12(17)/28/66 TD-LTE: Bands 38/41 |
GSM: 850/900/1800/1900 MHz WCDMA:B1/B5/B8 FDD-LTE: Bands 1/3/5/8 TD-LTE: Bands 38/40/41 |
GSM: 850/900/1800/1900 MHz WCDMA: Bands 1/5/8 FDD-LTE: Bands 1/3/5/7/8/20/28 TD-LTE: Bands 38/40/41 |
GSM: 850/900/1800/1900 MHz WCDMA: Bands 1/5/8 FDD-LTE: Bands 1/3/5/7/8/20/28 TD-LTE: Bands 38/40/41 |
| 5G uplink/downlink rate (Not to be published on our official website) |
Not supported | Not supported | Not supported | Not supported |
| 4G uplink/downlink rate (Not to be published on our official website) |
Downlink: 150 Mbps Uplink: 75 Mbps |
Downlink: 150 Mbps Uplink: 75 Mbps |
Downlink: 150 Mbps Uplink: 75 Mbps |
Downlink: 150 Mbps Uplink: 75 Mbps |
| Link boost | Supported | Supported | Supported | Supported |
18.SIM card |
||||
| SIM card type and size | Nano-SIM card | Nano-SIM card | Nano-SIM card | Nano-SIM card |
| SIM card tray type and material | 3-slot plastic tray for 2 cards | 3-slot plastic tray for 2 cards | 3-slot plastic tray for 2 cards | 3-slot plastic tray for 2 cards |
| Notes on single/dual cards | MX Open market/Virgin/OUITelcel/AT&T " single-cards； “CO Claro”single-cards；“CL Claro”single-cards；“PE Claro”single-cards；“GT Claro”single-cards；“HT Claro”single-cards；All the rest support dual cards |
dual cards | "KE Safaricom" single-cards；“TR Open market/Turkcell/Vodafone/TurkTelekom”single-cards；"ZA MTN/Vodacom " single-cards;All the rest support dual cards | dual cards |
19.Buttons and connectors |
||||
| Audio jack | 3.5 mm | 3.5 mm | 3.5 mm | 3.5 mm |
| Data port | USB Type-C | USB Type-C | USB Type-C | USB Type-C |
| Transfer protocol (USB) | USB 2.0 | USB 2.0 | USB 2.0 | USB 2.0 |
| Pins (USB) | 14 | 14 | 14 | 14 |
| Navigation buttons | No physical navigation buttons | No physical navigation buttons | No physical navigation buttons | No physical navigation buttons |
| Power button | Front right side | Front right side | Front right side | Front right side |
| Volume buttons | 2 volume buttons at the left side (with the screen facing upward) | 2 volume buttons at the left side (with the screen facing upward) | 2 volume buttons at the left side (with the screen facing upward) | 2 volume buttons at the left side (with the screen facing upward) |
20.Positioning |
||||
| Satellite positioning | Built-in GPS, A-GPS, BeiDou, GLONASS, GALILEO and QZSS positioning systems supported. | Built-in GPS, A-GPS, BeiDou, GLONASS, GALILEO and QZSS positioning systems supported. | Built-in GPS, A-GPS, BeiDou, GLONASS, GALILEO and QZSS positioning systems supported. | Built-in GPS, A-GPS, BeiDou, GLONASS, GALILEO and QZSS positioning systems supported. |
| Dual-frequency dual-antenna positioning | Not supported | Not supported | Not supported | Not supported |
| Other | Wi-Fi positioning, mobile network-based positioning, and electronic compass | Wi-Fi positioning, mobile network-based positioning, and electronic compass | Wi-Fi positioning, mobile network-based positioning, and electronic compass | Wi-Fi positioning, mobile network-based positioning, and electronic compass |
| Map apps | Supports all third-party map apps | Supports all third-party map apps | Supports all third-party map apps | Supports all third-party map apps |
| Dual-frequency GPS | Single-frequency GPS | Single-frequency GPS | Single-frequency GPS | Single-frequency GPS |
21.Fingerprint & face recognition |
||||
| Fingerprint unlock time | Screen turned off: <400 ms Screen turned on: <200 ms Permitted fluctuation: 50 ms |
Screen turned off: <400 ms Screen turned on: <200 ms Permitted fluctuation: 50 ms |
Screen turned off: <400 ms Screen turned on: <200 ms Permitted fluctuation: 50 ms |
Screen turned off: <400 ms Screen turned on: <200 ms Permitted fluctuation: 50 ms |
| Face unlock time | Screen turned off: <700 ms Screen turned on: <620 ms Permitted fluctuation: 50 ms |
Screen turned off: <700 ms Screen turned on: <620 ms Permitted fluctuation: 50 ms |
Screen turned off: <700 ms Screen turned on: <620 ms Permitted fluctuation: 50 ms |
Screen turned off: <700 ms Screen turned on: <620 ms Permitted fluctuation: 50 ms |
| Fingerprint | Side fingerprint unlock | Side fingerprint unlock | Side fingerprint unlock | Side fingerprint unlock |
| Fingerprint payment | Supported | Supported | Supported | Supported |
| Face recognition | Supported | Supported | Supported | Supported |
| Face recognition payment | Not supported | Not supported | Not supported | Not supported |
22.Sensors |
||||
| Sensor type | Geomagnetic sensor, light sensor, proximity sensor, accelerometer, gravity sensor, and step counting function supported. | Geomagnetic sensor, light sensor, proximity sensor, accelerometer, gravity sensor, and step counting function supported. | Geomagnetic sensor, light sensor, proximity sensor, accelerometer, gravity sensor, and step counting function supported. | Geomagnetic sensor, light sensor, proximity sensor, accelerometer, gravity sensor, and step counting function supported. |
| Infrared blaster | Not supported | Not supported | Not supported | Not supported |
23.Battery & charging |
||||
| Battery capacity | 4890 mAh/18.92 Wh (Min) 5000 mAh/19.35 Wh (Typ) |
4890 mAh/18.92 Wh (Min) 5000 mAh/19.35 Wh (Typ) |
4890 mAh/18.92 Wh (Min) 5000 mAh/19.35 Wh (Typ) |
4890 mAh/18.92 Wh (Min) 5000 mAh/19.35 Wh (Typ) |
| Suitable temperature range | VOOC charging not supported | VOOC charging not supported | VOOC charging not supported | VOOC charging not supported |
| Adapter model/parameters | I/P: 100–240VAC, 0.4A O/P: 5VDC, 2A |
I/P: 100–240VAC, 0.4A O/P: 5VDC, 2A |
I/P: 100–240VAC, 0.4A O/P: 5VDC, 2A |
I/P: 100–240VAC, 0.4A O/P: 5VDC, 2A |
| Standard charger power | 10W | 10W | 10W | 10W |
| Energy density | 729 Wh/L | 729 Wh/L | 729 Wh/L | 729 Wh/L |
| Maximum audio playback time | 33 hours | 33 hours | 33 hours | 33 hours |
| Maximum call time | 34 hours | 34 hours | 34 hours | 34 hours |
| Maximum video playback time | 18 hours | 18 hours | 18 hours | 18 hours |
| Maximum standby time | 381 hours | 381 hours | 381 hours | 381 hours |
| Maximum standby time (4G) | 381 hours | 381 hours | 381 hours | 381 hours |
| Maximum standby time (3G) | 381 hours | 381 hours | 381 hours | 381 hours |
| Maximum standby time (2G) | 381 hours | 381 hours | 381 hours | 381 hours |
| Maximum audio playback time (through speaker at medium volume) | 33 hours | 33 hours | 33 hours | 33 hours |
| Maximum video playback time (through speaker at medium volume) | 18 hours | 18 hours | 18 hours | 18 hours |
| Fast charging | Not supported | Not supported | Not supported | Not supported |
| Flash charging | Not supported | Not supported | Not supported | Not supported |
| Wireless charging | Not supported | Not supported | Not supported | Not supported |
| Charger model | OP52JAUH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52YAUH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52KAUH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52JBUH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52GDIH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52GDIN Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CDIH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CDIN Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52YBIH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52AAIN Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAEH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52KAEH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52JAEH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAED Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAEH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52JAYH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52KAYH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52JAAH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAPH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAYH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A |
OP52JAUH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52YAUH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52KAUH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52JBUH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52GDIH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52GDIN Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CDIH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CDIN Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52YBIH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52AAIN Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAEH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52KAEH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52JAEH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAED Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAEH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52JAYH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52KAYH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52JAAH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAPH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAYH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A |
OP52JAUH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52YAUH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52KAUH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52JBUH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52GDIH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52GDIN Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CDIH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CDIN Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52YBIH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52AAIN Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAEH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52KAEH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52JAEH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAED Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAEH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52JAYH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52KAYH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52JAAH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAPH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A OP52CAYH Input: 100–240V, 50/60Hz 0.4A Output: 5.0V DC 2A |
OP52JAUH Input: 100–240V, 50/60 Hz 0.4A Output: 5.0V DC 2A OP52YAUH Input: 100–240V, 50/60 Hz 0.4A Output: 5.0V DC 2A OP52KAUH Input: 100–240V, 50/60 Hz 0.4A Output: 5.0V DC 2A OP52JBUH Input: 100–240V, 50/60 Hz 0.4A Output: 5.0V DC 2A |
| Reverse charging | Not supported | Not supported | Not supported | Not supported |
| Breathing light during charging | No | No | No | No |
| Time required for a full charge | Around 200 min | Around 200 min | Around 200 min | Around 200 min |
| Battery model | BLP805 | BLP805 | BLP805 | BLP805 |
24.Other hardware |
||||
| SAR | FCC SAR (Latin America): Head: 1.15 W/kg Body: 0.55 W/kg Hotspot: 1.18 W/kg |
CE SAR (Asia Pacific): Head: 0.99 W/kg Body: 1.22 W/kg Indian SAR Head: 1.18 W/kg Body: 0.84 W/kg |
CE SAR (All frequency bands): Head: 0.99 W/kg Body: 1.24 W/kg CE SAR (Europe): Head: 0.99 W/kg Body: 1.24 W/kg Limb: 2.74 W/kg |
/ |
| Sound effects | None | None | None | None |
| Hi-Fi | Not supported | Not supported | Not supported | Not supported |
| Hi-Fi chip (If Hi-Fi is supported) | Not supported | Not supported | Not supported | Not supported |
| Standalone or integrated audio decoder chip | Integrated audio decoder chip | Integrated audio decoder chip | Integrated audio decoder chip | Integrated audio decoder chip |
| Audio certification | No | No | No | No |
| Vibration motor | Rotor motor | Rotor motor | Rotor motor | Rotor motor |
| Water resistance rating | IPX4, enough for daily routine | IPX4, enough for daily routine | IPX4, enough for daily routine | IPX4, enough for daily routine |
| Heat dissipation mechanism | Middle frame with high thermally conductive material + Front cover with 2-layer graphite + Rear cover with 3-layer graphite | Middle frame with high thermally conductive material + Front cover with 2-layer graphite + Rear cover with 3-layer graphite | Middle frame with high thermally conductive material + Front cover with 2-layer graphite + Rear cover with 3-layer graphite | Middle frame with high thermally conductive material + Front cover with 2-layer graphite + Rear cover with 3-layer graphite |
| Top ports and holes (From left to right) | No | No | No | No |
| Bottom ports and holes (From left to right with screen facing upward) | Earphone jack, microphone, USB port, and speaker | Earphone jack, microphone, USB port, and speaker | Earphone jack, microphone, USB port, and speaker | Earphone jack, microphone, USB port, and speaker |
| Button backlight | / | / | / | / |
| Expansion card | Supported | Supported | Supported | Supported |
25.Speaker/Microphone |
||||
| Number of speakers | 1/Bottom right (with the screen facing up), Kernel size：1217 | 1/Bottom right (with the screen facing up),Kernel size： 1217 | 1/Bottom right (with the screen facing up), Kernel size：1217 | 1/Bottom right (with the screen facing up),Kernel size： 1217 |
| MIC | 1 mic | 1 mic | 1 mic | 1 mic |
| Ultra-linear/Super-dynamic/Super-balanced speakers | Conventional speaker | Conventional speaker | Conventional speaker | Conventional speaker |
| Noise cancellation | Single-microphone noise cancellation | Single-microphone noise cancellation | Single-microphone noise cancellation | Single-microphone noise cancellation |
26.Operating environment |
||||
| Operating temperature | 0°C–35°C (32°F–95°F) | 0°C–35°C (32°F–95°F) | 0°C–35°C (32°F–95°F) | 0°C–35°C (32°F–95°F) |
| Storage temperature | -20°C–45°C (-4°F–113°F) | -20°C–45°C (-4°F–113°F) | -20°C–45°C (-4°F–113°F) | -20°C–45°C (-4°F–113°F) |
| Relative humidity | 5%–95% (noncondensing state) | 5%–95% (noncondensing state) | 5%–95% (noncondensing state) | 5%–95% (noncondensing state) |
| Operating altitude | Up to 3,000 meters (10,000 feet) according to testing data | Up to 3,000 meters (10,000 feet) according to testing data | Up to 3,000 meters (10,000 feet) according to testing data | Up to 3,000 meters (10,000 feet) according to testing data |
27.Phone accessories |
||||
| Package contents | Phone x 1 Earphones x 1 USB cable x 1 Charger x 1 SIM ejector tool x 1 Protective case x 1 Quick start guide x 1 Warranty card x 1 |
Phone x1 USB cable x 1 Charger x1 SIM ejector tool x1 Protective case x1 Quick start guide x 1 Warranty card x 1 |
Phone x 1 Earphone x 1 (Only for South Africa, France, Italy, Spain, Netherlands, German, Belgium) USB cable x 1 Charger x 1 SIM ejector tool x 1 Protective case x 1 Quick start guide x 1 Warranty card x 1 |
Phone x1 USB cable x 1 Charger x1 SIM ejector tool x1 Protective case x1 Quick start guide x 1 Warranty card x 1 |
| SIM ejector tool | Yes | Yes | Yes | Yes |
| Material of protective case | TPU | TPU | TPU | TPU |
| Style of protective case | Elastic and transparent | Elastic and transparent | Elastic and transparent | Elastic and transparent |
| Is a screen protector available? | Yes | Yes | Yes | Yes |
| USB cable length and color | 1-meter white cable | 1-meter white cable | 1-meter white cable | 1-meter white cable |
| TF card | Not supported | Not supported | Not supported | Not supported |
| Plastic film sealing | OK | OK | OK | OK |
28.Important tips |
||||
| Tips | / | / | / | / |
29.Earphones |
||||
| Speaker size | Ø14.2mm | Ø14.2mm | Ø14.2mm | Ø14.2mm |
| Rated power | 3mW | 3mW | 3mW | 3mW |
| Sensitivity | 110±1.5 dB | 110±1.5 dB | 110±1.5 dB | 110±1.5 dB |
| Impedance of earphones | 54 ohm | 54 ohm | 54 ohm | 54 ohm |
| Earphone model | MH 156 | MH 156 | MH 156 | MH 156 |
| Earphone standards | US standards | US standards | US standards | US standards |
| Frequency range | 20 Hz to 20 kHz | 20 Hz to 20 kHz | 20 Hz to 20 kHz | 20 Hz to 20 kHz |
| Push-to-talk on earphones | Supported | Supported | Supported | Supported |
| Wake voice assistant | Not supported: Speak through the earphone MIC to wake the voice assistant Supported: Long press the button on the wired earphone to wake the voice assistant |
Not supported: Speak through the earphone MIC to wake the voice assistant Supported: Long press the button on the wired earphone to wake the voice assistant |
Not supported: Speak through the earphone MIC to wake the voice assistant Supported: Long press the button on the wired earphone to wake the voice assistant |
Not supported: Speak through the earphone MIC to wake the voice assistant Supported: Long press the button on the wired earphone to wake the voice assistant |
| Volume control | Not supported | Not supported | Not supported | Not supported |
| Switching songs | Double press to switch to the next song | Double press to switch to the next song | Double press to switch to the next song | Double press to switch to the next song |
| In-ear monitoring | Not supported | Not supported | Not supported | Not supported |
| Earphone jack | 3.5 mm | 3.5 mm | 3.5 mm | 3.5 mm |
30.Earphones (Indian standards for the Indian market) |
||||
| Speaker size | N/A | Ø14.2mm | N/A | N/A |
| Rated power | N/A | 3mW | N/A | N/A |
| Sensitivity | N/A | 110±1.5 dB | N/A | N/A |
| Impedance of earphones | N/A | 54 ohm | N/A | N/A |
| Earphone model | N/A | MH 156 | N/A | N/A |
| Earphone standards | N/A | India | N/A | N/A |
| Frequency range | N/A | 20 Hz to 20 kHz | N/A | N/A |
| Push-to-talk on earphones | N/A | Supported | N/A | N/A |
| Wake voice assistant | N/A | Not supported: Speak through the earphone MIC to wake the voice assistant Supported: Long press the button on the wired earphone to wake the voice assistant |
N/A | N/A |
| Volume control | N/A | India | N/A | N/A |
| Switching songs | N/A | Double press to switch to the next song | N/A | N/A |
| In-ear monitoring | Not supported | Not supported | Not supported | Not supported |
31.Packaging specifications (for international versions) |
||||
| Region 1 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 2 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 3 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 4 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 5 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 6 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 7 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 8 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 9 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 10 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 11 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 12 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 13 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 14 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Region 15 | N/A | N/A | N/A | N/A |
| SAR & certificate number | N/A | N/A | N/A | N/A |
| Frequency bands | 2G: GSM 850/900/1800/1900 MHz 3G: UMTS (WCDMA) bands 1/2/4/5/6/8/19 4G: TD-LTE bands 38/41 (2535–2655 MHz) 4G: LTE FDD bands 1/2/3/4/5/7/8/12/17/18/19/28/26/66 |
2G: GSM 850/900/1800/1900 MHz 3G: UMTS (WCDMA) bands 1/5/8 4G: TD-LTE bands 38/40/41 (2535–2655 MHz) 4G: LTE FDD bands 1/3/5/8 Indonesia: GSM: 900/1800 MHz WCDMA: 900/2100 MHz LTE FDD: Bands 1/3/5/8 LTE TDD: Band 40 |
2G: GSM 850/900/1800/1900 MHz 3G: UMTS (WCDMA) bands 1/5/8 4G: TD-LTE bands 38/40/41 (2496-2690 MHz) 4G: LTE FDD bands 1/3/5/7/8/20/28 |
2G: GSM 850/900/1800/1900 MHz 3G: UMTS (WCDMA) bands 1/5/8 4G: TD-LTE bands 38/40/41 (2496-2690 MHz) 4G: LTE FDD bands 1/3/5/7/8/20/28 |
| Model name | N/A | N/A | N/A | N/A |
| Table for power information | N/A | N/A | N/A | N/A |
| Battery voltage and charging current | N/A | N/A | N/A | N/A |
| Camera parameters | N/A | N/A | N/A | N/A |
| Warranty card number in Indonesia | N/A | N/A | N/A | N/A |
| MRP (Manufacturers' recommended price) in India | N/A | N/A | N/A | N/A |
| Hi-Res | N/A | N/A | N/A | N/A |
| Water resistance | N/A | N/A | N/A | N/A |
| Laser detection auto focus (LDAF) | N/A | N/A | N/A | N/A |
Related Articles
OPPO A16（CPH2269/CPH2275）& A16s（CPH2271）& A54s（CPH2273）Disassembly and Assembly Video
Views: 2 • Likes: 0
Read ArticleOPPO A16（CPH2269/CPH2275）& A16s（CPH2271）& A54s（CPH2273）Aftersales BOM
Views: 7 • Likes: 0
Read ArticleOPPO A16（CPH2269/CPH2275）& A16s（CPH2271）& A54s （CPH2273）Service Manual
Views: 5 • Likes: 0
Read Article
